Product Introduction

SP-1310/2210AS

Electronic Pattern Sewing Machine

  • SP-1310AS-HS/MS
  • SP-1310AS-H/M/X
  • SP-1310AS-X/RQ
  • SP-1310AS-H/FZ
  • SP-2210AS-H/M/X

SP series electronic pattern sewing machine with fastest speed, efficient and beautiful sewing line, wider sewing range,
stronger applicability, using energy-saving technology,it is more environmental friendly, mainly used in all kinds
of men and women apparel industry, denim, knits, intimates, luggage, footwear and other purposes.

Product Features

  • The machine is equipped with standard slot of USB port. By using USB disc or card reader,it can achive the data input and output for various storage devices.
  • Machine is Compatible with the patterns of 210D,210E and PLK patterns sewing machine series.
  • Powerful data compatibility can greatly reduce the repeated labor of inputing program.
  • Due to the adoption of the direct drive computer motor of Supreme company, the start/stop response is rapid and smooth, and the running time of the machine is reduced about 19% comparing with the traditional model, and the production efficiency is further improved.

Characters

  • Substantial tension
  • Quality stitching
  • Thread breakage detector
  • Low power consumption, high speed, high efficiency
  • Editable pattern
  • Strong penetration needle
  • Extended output
  • Two types of editing softwares.
  • Electronic thread clamping function.

Technical Parameters

Model and Standard +

  • Model
    Line
    Highest sewing speed
    Sewing area
    Cloth feeding mode
    Stitch Length
    Maximum stitch amount
    2- step presser foot
    Storage amount of stitches
    Rising amount of intermittent foot presser
    Stroke by intermittent presser foot
    Thread Wiper
    Cutting device
    Customer program amount
    Recyle programme No.
    Motor
    Weight
    Power
    Air pressure
    Work Clamp Height
    Hook
    Data storage way
    Machine size
    Packing size
  • SP-1310AS-HS/MS
    Sing-needle flat seam
    2,800 rpm
    Max.130×100mm
    Intermittent feeding(Pulse motor drive mode)
    0.05-12.7mm
    20,000 needles/1 pattern
    Integrated presser foot; Divided presser foot
    500000 stitch can be stored in build-inmomery
    22mm
    0 or 2-10mm(Factory defaults:3mm)
    Standard facility
    Standard facility
    50
    9
    AC servomotor 550W
    170kg
    Single phase 220V,3-phase 380V
    0.5Mpa、1.8L/min
    HS/MS:maximum 25 mm -0 H/M/X:maximum 30 mm
    Double Shuttle Hook
    USB
    1200×895×1250
    1300×1000×1350
  • SP-1310AS-H/M/X
    Sing-needle flat seam
    2,800rpm
    Max.130×100mm
    Intermittent feeding(Pulse motor drive mode)
    0.05-12.7mm
    20,000 needles/1 pattern
    Integrated presser foot; Divided presser foot
    500000 stitch can be stored in build-inmomery
    22mm
    0 or 2-10mm(Factory defaults:3mm)
    Standard facility
    Standard facility
    50
    9
    AC servomotor 550W
    170kg
    Single phase 220V,3-phase 380V
    0.5Mpa、1.8L/min
    HS/MS:maximum 25 mm -0 H/M/X:maximum 30 mm
    Double Shuttle Hook
    USB
    1200×895×1250
    1300×1000×1350
  • SP-1310AS-X/RQ
    Sing-needle flat seam
    2,800 rpm
    Max.130×100mm
    Intermittent feeding(Pulse motor drive mode)
    0.05-12.7mm
    20,000 needles/1 pattern
    Integrated presser foot; Divided presser foot
    500000 stitch can be stored in build-inmomery
    22mm
    0 or 2-10mm(Factory defaults:3mm)
    Standard facility
    Standard facility
    50
    9
    AC servomotor 550W
    170kg
    Single phase 220V,3-phase 380V
    0.5Mpa、1.8L/min
    HS/MS:maximum 25 mm -0 H/M/X:maximum 30 mm
    Double Shuttle Hook
    USB
    1200×895×1250
    1300×1000×1350
  • SP-1310AS-H/FZ
    Sing-needle flat seam
    2,800 rpm
    Max.130×100mm
    Intermittent feeding(Pulse motor drive mode)
    0.05-12.7mm
    20,000 needles/1 pattern
    Integrated presser foot; Divided presser foot
    500000 stitch can be stored in build-inmomery
    22mm
    0 or 2-10mm(Factory defaults:3mm)
    Standard facility
    Standard facility
    50
    9
    AC servomotor 550W
    170kg
    Single phase 220V,3-phase 380V
    0.5Mpa、1.8L/min
    HS/MS:maximum 25 mm -0 H/M/X:maximum 30 mm
    Double Shuttle Hook
    USB
    1200×895×1250
    1300×1000×1350
  • SP-2210AS-H/M/X
    Sing-needle flat seam
    2,800 rpm
    220×100mm
    Intermittent feeding(Pulse motor drive mode)
    0.05-12.7mm
    20,000 needles/1 pattern
    Divided presser foot
    500000 stitch can be stored in build-inmomery
    22mm
    0 or 2-10mm(Factory defaults:3mm)
    Standard facility
    Standard facility
    50
    9
    AC servomotor 550W
    170kg
    Single phase 220V,3-phase 380V
    0.5Mpa、1.8L/min
    HS/MS:maximum 25 mm -0 H/M/X:maximum 30 mm
    Double Shuttle Hook
    USB
    1200×900×1300
    1400×1000×1400
